Direct-to-card dye-sublimation/resin thermal transfer
300 dots per inch
High-quality mode: 300 x 600 dots per inch; enhanced text, bar code and graphics printing 300 x 1200 dots per inch; enhanced text and bar code
Up to 200 cards/hour – single sided YMCK printing with single sided lamination
Up to 175 cards/hour – dual sided YMCK-K printing with single sided lamination
Up to 185 cards per hour (one side print and lamination with tactile) YMCK
Up to 150 cards per hour (two sided printing and one sided lamination with tactile) YMCK-K
Card input hopper capacity – 100 (up to 200)
Card output hopper capacity – 100
Reject hopper capacity – 10
Printer: 23.2 in. x 10.6 in. x 20.2 in. (589 mm X 270 mm X 513 mm)
Printer with impressor: 26.6 in. x 10.6 in. x 20.2 in. (675 mm x 270 mm x 513 mm)
Printer with single-sided laminator: 29.92 lbs (13.6 kg)
Printer with dual-sided laminator: 32.78 lbs (14.9 kg)
Printer with dual-sided laminator and impressor: 36.96 lbs (16.8 kg)
Windows® 10, 8, and 7 (32/64 bit), Windows Server 2012 (64 bit), 2008 (64 bit)
36-month standard depot warranty
